ECTMarine werkboten zijn heavy duty werkboten voor verschillende toepassingen in de maritieme industrie. Het algemene ontwerp is een multicat-type schip, dat zowel in ondiepe wateren als in kustgebieden kan werken. De schepen zijn verkrijgbaar in verschillende maten en met een verscheidenheid aan opties en in verschillende configuraties, zoals baggerondersteuningsvaartuig, bevoorradingsschip, vervoerder, duwboot/sleepboot. De werkboten hebben een ruim dek en zijn manoeuvreerbaar om werkzaamheden in krappe ruimtes uit te voeren.
Propulsion
Propulsion engine: Doosan, Volvo, Caterpillar
Power (approx): 230 kW
Propellers: 1x 4 blade fixed pitch propellers
Steering system: hydraulic plate rudder
Main Dimensions
Length overall: 12 m
Beam: 5 m
Depth at side: 1,5 m
Draught: 1 m
Deck equipment
Anchor handeling winch
Line pull first layer: 30 kN
Towing bitt
Bow roller
Wooden work deck
Ship systems: Compass, VHF, Fire extinguishers
Navigation and interior lights
Electric bilge pump
Mechanical ventilation
Internal cooling system
Hydraulic system powered by main engine
Grease pump and toolkit
Tank capacities
Fuel oil: 4 m3
Electric installation
Alternator: 24V DC
Quantity: 1x
Capacity: 1x 60A
Batteries
Quantity: 2x
Capacity: 200 Ah
Performance
Bollard pull ahead: 3 ton
Speed (approx): 6,5 knots
Deck crane (SWL): 9,6 tm
Classification (optional)
Bureau Veritas / Holland Register
Class I X HULL · MACH special service / Workboat Coastal Area
Main characteristics
The hull is a fully welded, longitudinally stiffened©
The main marine engine with reduction gearbox is located in
the engine room.
Propulsion of the workboat will be realized by a fixed pitch propeller.
Steering is with plate rudder and powered by hydraulic steering gear.
The wheelhouse is constructed of steel and has acoustic and thermal insulation.
Optional Equipment
Diesel generator 230V with main switch board
Anchor mooring winch
Radar system
GPS
