ECT MARINE
WORKBOAT 104

ECTMarine workboats are heavy duty workboats for different applications in the marine industry. The general design is a multicat type vessel, that can work in shallow waters as well as coastal area’s. The vessels are available in different sizes and with a variety of options and in different configurations such as dredge support vessel, supply vessel, carrier, pusher/ tug. The workboats have a spacious deck and are maneuverable to perform activities in confined area’s.

PRODUCTDATA
WORKBOAT 104

Propulsion

Propulsion engine: Doosan

Power (approx): 166 kW

Propellers: 1x 4 blade fixed pitch propellers

Steering system: hydraulic plate rudder

Main Dimensions

Length overall: 10 m

Beam: 4 m

Depth at side: 1,5 m

Draught: 1 m

Deck equipment

Anchor handeling winch

Line pull first layer: 25 kN

Towing bitt

Bow roller

Wooden work deck

Ship systems: Compass, VHF, Fire extinguishers

Navigation and interior lights

Electric bilge pump

Mechanical ventilation

Internal cooling system

Hydraulic system powered by main engine

Grease pump and toolkit

Tank capacities

Fuel oil: 4 m3

Electric installation

Alternator: 24V DC

Quantity: 1x

Capacity: 1x 60A

Batteries

Quantity: 2x

Capacity: 200 Ah

Performance

Bollard pull ahead: 2 ton

Speed (approx): 7 knots

Deck crane (SWL): 74 kNm

Classification (optional)

Bureau Veritas / Holland Register
Class I X HULL · MACH special service / Workboat Coastal Area

Main characteristics

The hull is a fully welded, longitudinally stiffened©

The main marine engine with reduction gearbox is located in

the engine room.

Propulsion of the workboat will be realized by a fixed pitch propeller.

Steering is with plate rudder and powered by hydraulic steering gear.

The wheelhouse is constructed of steel and has acoustic and thermal insulation.

Optional Equipment

Diesel generator 230V with main switch board

Anchor mooring winch

Radar system

GPS
